G084SN03 V3
Brand:AUO
Model P/N: G084SN03 V3
Diagonal Size: 8.4 inch
Pixels: 800×600
Pixel Pitch(mm): 0.213x 0.213 mm
Interface Type: LVDS
Luminance: 250 cd/m2
Viewing Angle: Typ.(80/60/80/80
Active Area(mm): 170.4(H) x 127.8(V) mm
Physical Size(mm): 203.0(W) x 142.5(H) x 5.7(D) (typ.) mm
Contrast Ratio: Typ.(600:1;Min(400:1
Response Time: Typ.30;Max 50
Work Mode: TN, Normally White
Surface Treatment: Anti-glare, Hardness 3H
Color Depth: 262K(6-bit) / 16.2M(8-bit)
Backlight: WLED , 30K hours , with LED Driver
Input Voltage: 3.3 V
Storage Temp: -20 ~ +70 (°C)
Operating Temp: -20 ~ +70 (°C)
Touchscreen: Optional
Net Weight: 190 (typ)
Package: M ax. Capacity : 30 LCD M odules/Carton.
Introduction
This specification applies to the 8.4 inch color TFT LCD module G084SN03 V3.?This module is designed for display units for Industrial Applications.?The screen format is intended to support the SVGA (800(H) x 600(V)) screen and 16.2M (RGB?8-bits) or 262k colors (RGB 6-bits).?All input signals are LVDS interface compatible.?LED Driver is embedded.?This is a RoHS product.
